Product Details

  • WHD instant print labelling machine
  • WHD instant print labelling machine

WHD instant print labelling machine

Wechat consulting

微信掃碼咨詢
Consult now
+86 0769-86298863

Details

Application Requirements

1. Instant printing of product information --- instant labeling
2. Plane/side labeling requirements


Labeling Instructions


1. The PC system transmits data to the computer, the computer sends the data to the printer, the printer prints the label and peels off the label, the suction cup absorbs the label, and the cylinder pushes the suction cup to push the label to the bag sticking position
2. The photoelectricity detects the item, starts and completes the labeling

Labeling Requirements

1. Make a label, single row, label spacing 2-3mm
2. Label and release paper margin: 2-3mm
3. Label backing paper material: Glassine backing paper
4. Label die-cutting accuracy: ±0.2mm, can not be cut to the bottom paper
5. Outer diameter of label roll: ≤300mm
6. Inner diameter of paper core: 76.2mm

technical parameter


Printer model

American Zebra ZE500-4

printing method

Thermal transfer/thermal

print resolution

300dpi

printing speed

254mm/s

print range

Width 104mm, length 300mm

Induction mode

Gap induction (transmissive), reflective

media type

Coated paper, synthetic paper, glassine backing paper

Paper roll size

Label roll outer diameter: ≤300mm, paper core inner diameter: 76.2mm
